Product
Code |
#
Outputs |
Input
Voltage |
Output
Voltage |
Input
Current |
Output
Current |
Output
Power |
Protocol |
IP
Rating |
Connection | Dimensions | Weight | Warranty |
| ACC-DR-CV-36A-12-DA | 1 | 100-240VAC | 12VDC | 0.4A @ 230VAC | 3A | 36W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 175x44x30mm | 190g | 3 years |
| ACC-DR-CV-36A-24-DA | 1 | 100-240VAC | 24VDC | 0.4A @ 230VAC | 1.5A | 36W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 175x44x30mm | 190g | 3 years |
| ACC-DR-CV-75B-12-DA | 1 | 200-240VAC | 12VDC | 0.4A @ 230VAC | 6.25A | 75W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 293x43x30mm | 300g | 3 years |
| ACC-DR-CV-75B-24-DA | 1 | 200-240VAC | 24VDC | 0.4A @ 230VAC | 3.12A | 75W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 293x43x30mm | 300g | 3 years |
| ACC-DR-CV-100A-24-DA | 1 | 200-240VAC | 24VDC | 0.5A @ 230VAC | 4.17A | 100W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 293x43x30mm | 300g | 3 years |
| ACC-DR-CV-150A-12-DA | 1 | 100-240VAC | 12VDC | 0.8A @ 230VAC | 12.5A | 150W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 273x57x37mm | 790g | 3 years |
| ACC-DR-CV-150A-24-DA | 1 | 100-240VAC | 24VDC | 0.8A @ 230VAC | 6.25A | 150W |
DALI (IEC62386)
PUSH DIM |
IP20 | Push Terminals | 273x57x37mm | 790g | 3 years |
