Lucerna LED Bollards

Product Overview
Features
- Manufactured from anti-corrosive 6063 aluminium

- Robust construction

- IP65

- Solid acrylic diffuser

- Stem mounted design

- 3 year warranty
Description

An intrinsic addition to external areas of caution, Lucerna LED bollards are a contemporary take on the traditional floor mounted candelabra.

The distinctive design incorporates a solid acrylic diffuser affixed upon an elegant mounting stem which mimics a wax candle, and can be utilized creatively to generate engaging, illuminated guidance systems or local ambient illumination for outdoor landscaping areas.

Constant current operation via remote LED driver, Lucerna LED bollards are installed in series and can be dimmed through industry standard, 0/1-10V, DALI, DMX or TRIAC systems.

∅28mm and ∅60mm options with 600-1,200mm pole heights, the minimal design allows for incognito placement of dynamic local illumination outdoors.

Options
Height:
600mm | 800mm | 1,000mm
800mm | 1,000mm | 1,200mm
Colours:

2700K

3000K

4000K

6000K
Beam Angle:
Solid Acrylic Diffuser
Finish:
Matte Black
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
LED
Quantity
IP
Rating
Input
Voltage
Input
Current
Dimensions Mounting
Type
Weight Warranty
ARC-BO-LUC28-060 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 3VDC 300mA 600mm Soft Dig 250g 3 years
ARC-BO-LUC28-080 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 3VDC 300mA 800mm Soft Dig 270g 3 years
ARC-BO-LUC28-100 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 3VDC 300mA 1,000mm Soft Dig 290g 3 years
ARC-BO-LUC60-082 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 10VDC 600mA 820mm Soft Dig 500g 3 years
ARC-BO-LUC60-102 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 10VDC 600mA 1,020mm Soft Dig 540g 3 years
ARC-BO-LUC60-122 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 10VDC 600mA 1,220mm Soft Dig 580g 3 years
ARC-BO-LUC28-060-SW 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 600mm Soft Dig 250g 3 years
ARC-BO-LUC28-080-SW 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 800mm Soft Dig 270g 3 years
ARC-BO-LUC28-100-SW 1W 70lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 1,000mm Soft Dig 290g 3 years
ARC-BO-LUC60-082-SW 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 820mm Soft Dig 500g 3 years
ARC-BO-LUC60-102-SW 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 1,020mm Soft Dig 540g 3 years
ARC-BO-LUC60-122-SW 6W 430lm 2700K | 3000K | 4000K | 6000K ≥90 Solid Acrylic
Diffuser
1 IP65 100-265VAC - 1,220mm Soft Dig 580g 3 years
Dimensions
Control Options
0/1 - 10V
2.4GH
z
RF
DALI
DMX
TRIAC
