LED Neon is a safe, durable, long lasting alternative to conventional Neon.
Typically used in the architectural or commercial industries to illuminate buildings, structures & retail spaces.
Operating at 24VDC, the 11.5x29mm can be operated upto 30m in a single length, to provide uninterrupted, uniform lighting.
11.5x29mm has a rounded illumination surface providing 270° output making it the ideal product for architectural contour lighting & signage.
|
Product
Code |
Power |
Lumen
Output |
LED
Colour |
CRI |
Beam
Angle |
IP
Rating |
Bend
Direction |
Input
Voltage |
Dimensions |
Cut
Increments |
Max Length
Single End |
Max Length
Double End |
Weight | Warranty |
| ARC-NE-11529-50K | 14W/m | 430lm/m | 5700K | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-40K | 14W/m | 390lm/m | 4000K | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-30K | 14W/m | 370lm/m | 3000K | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-27K | 14W/m | 350lm/m | 2700K | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-RE1 | 10W/m | - | Red | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 15m | 30m | 500g/m | 3 years |
| ARC-NE-11529-GR1 | 14W/m | - | Green | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-BL1 | 14W/m | - | Blue | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-AM1 | 10W/m | - | Amber | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 15m | 30m | 500g/m | 3 years |
| ARC-NE-11529-PI1 | 14W/m | - | Pink | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-PU1 | 14W/m | - | Purple | - | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 71.4mm | 12m | 24m | 500g/m | 3 years |
| ARC-NE-11529-DW | 22W/m | - |
3000K - 6000K
Adjustable |
≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 55.5mm | 5m | 10m | 500g/m | 3 years |
| ARC-NE-11529-RGB | 10W/m | - | RGB | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 100mm |
10m / 7m
(Injection Moulded) |
20m / 14m
(Injection Moulded) |
500g/m | 3 years |
| ARC-NE-11529-RGBW | 13.5W/m | - | RGBW | ≥90 | 160° | IP65 | IP67 | X & Y | 24VDC | 11.5x29mm | 100mm |
12m / 7m
(Injection Moulded) |
24m / 14m
(Injection Moulded) |
500g/m | 3 years |
