LED Neon is a safe, durable, long lasting alternative to conventional Neon.
Typically used in the architectural or commercial industries to illuminate buildings, structures & retail spaces.
Operating at 24VDC, the 9x18mm can be operated up to 30m in a single length, to provide uninterrupted, uniform lighting.
9x18mm has a flat illumination surface making it the ideal product for recessing applications where horizontal bending is required.
|
Product
Code |
Power |
Lumen
Output |
LED
Colour |
CRI |
Beam
Angle |
IP
Rating |
Bend
Direction |
Input
Voltage |
Dimensions |
Cut
Increments |
Max Length
Single End |
Max Length
Double End |
Weight | Warranty |
| ARC-NE-918-57K | 10W/m | 463lm/m | 5700K | ≥85 | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-40K | 10W/m | 420lm/m | 4000K | ≥85 | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-30K | 10W/m | 400lm/m | 3000K | ≥85 | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-27K | 10W/m | 380lm/m | 2700K | ≥85 | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-RE1 | 8.5W/m | - | Red | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 20m | 40m | 250g/m | 3 years |
| ARC-NE-918-GR1 | 10W/m | - | Green | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-BL1 | 10W/m | - | Blue | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-AM1 | 8.5W/m | - | Amber | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 20m | 40m | 250g/m | 3 years |
| ARC-NE-918-PI1 | 10W/m | - | Pink | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
| ARC-NE-918-PU1 | 10W/m | - | Purple | - | 160° | IP65 | IP67 | X & Y | 24VDC | 9x18mm | 83.34mm | 15m | 30m | 250g/m | 3 years |
