Omnis LED Spotlights

Product Overview
Features
- Simple fluid design

- Robust construction

- Double layer powder coating

- 5mm tempered glass

- Integrated LED driver

- Suitable for indoor & outdoor use

- Wide range of available beam angles

- 3 year warranty
Description

Omnis LED spotlights delicate appearance camouflages a powerful and robust source of architectural illumination to meet the requirements of refined, commercial lighting requirements.

The simple, 2-part fluid design of Omnis LED spotlights separates the driver from the body, greatly improving thermal management and increasing the lifetime of the Cree LED light source and LED driver.

Omnis LED spotlight are powder coated with a professional, fluorine carbon finishing which retains the beauty of the Omnis longer than any other architectural coating because it will resist environmental forces that can attack lower-performing products. Toughened glass to ensure all round durability.

With its timeless design and solid construction, Omins LED spotlights are a favourable solution for high-calibre internal or external lighting demands where form and reliability are crucial, such as airports, stations and sporting venues.

Options
Colours:

2700K

3000K

4000K

6000K



RGBW
Beam Angles:
5° | 8° | 12° | 12.5° | 20° | 24° | 30° | 38°
5x20° | 10x60° | 10x70° | 15x30°
Finishes:
Pearl Dark Grey (RAL9023)
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
#
LED's
IP
Rating
Input
Voltage
Input
Current
Control Dimensions Mounting
Type
Weight Warranty
ARC-SP-OMN3A 45W 4,050lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 12° | 20° | 30°
5x20° | 10x70°
5
(CREE XHP35)
IP66 100-305VAC - Switching ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3A-AN 45W 4,050lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 12° | 20° | 30°
5x20° | 10x70°
5
(CREE XHP35)
IP66 100-305VAC - 0-10V ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3A-DA 45W 4,050lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 12° | 20° | 30°
5x20° | 10x70°
5
(CREE XHP35)
IP66 100-305VAC - DALI ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3B 50W 4,500lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 8° | 12.5°
20° | 30° | 45° | 60°
10x60° | 15x30°
15
(CREE XP-G)
IP66 100-305VAC - Switching ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3B-AN 50W 4,500lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 8° | 12.5°
20° | 30° | 45° | 60°
10x60° | 15x30°
15
(CREE XP-G)
IP66 100-305VAC - 0-10V ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3B-DA 50W 4,500lm 2700K | 3000K | 4000K | 6000K ≥90 5° | 8° | 12.5°
20° | 30° | 45° | 60°
10x60° | 15x30°
15
(CREE XP-G)
IP66 100-305VAC - DALI ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3C-DM 50W 4,500lm 2700K | 3000K | 4000K | 6000K ≥90 12° | 24° | 38° 1
(CREE COB)
IP66 100-305VAC - DMX / RDM ∅147x235mm Surface 3.5kg 5 years
ARC-SP-OMN3D-DM 50W 2,100lm RGBW - 15° | 20° | 30°
15x60°
5
(CREE XM-L)
IP66 24VDC - DMX / RDM ∅147x235mm Surface 3.5kg 5 years
Dimensions
Control Options
0/1 - 10V
DALI
DMX
