18W Terra LED Spotlight

Product Overview
Features
- Surface Mounted

- Robust construction

- 12VDC operation

- Suitable for indoor & outdoor use

- Small size, high output

- Wide range of available beam angles

- 3 year warranty
Description

Terra LED Spotlights are compact, high output units designed for highlighting architectural features.

Powder coated with a marine grade finish, these units are at home in some of the most arduous conditions.

Operating at 12VDC, the 9LED luminaire is surface mounted and can be supplied in a wide variety of beam angles to create distinctive effects for different projects.

The 18W Terra LED Spotlight is perfect for illuminating architectural features, multiple stories or sculptures.

Options
Colours:

2700K

4000K

6000K



Red

Green

Blue

Amber

RGB
Beam Angles:
15° | 20° | 25° | 45° | 60° | 120°
Finishes:
Black | White
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
LED
Quantity
IP
Rating
Input
Voltage
Input
Current
Dimensions Mounting
Type
Weight Warranty
ARC-SP-TER118 18W 1,215lm 2700K | 4000K | 6000K
Red | Green | Blue | Amber
≥80 15° | 25°
45° | 60° | 120°
9 IP65 12VDC 1.5A ∅125mm Surface 1.5kg 3 years
ARC-SP-TER118-RGB 18W - RGB - 15° | 25°
45° | 60° | 120°
9
(3R, 3G, 3B)
IP65 12VDC 0.5A/
channel
∅125mm Surface 1.5kg 3 years
Dimensions
Control Options
0/1 - 10V
2.4GH
z
RF
BLE
DALI
DMX
TRIAC
