Abdo LED Cove Light is a linkable, concealed illumination system for commercial applications.
Bringing together uber reliable linear LED Tape, high performance LED driver and aluminium mounting extrusion, the Abdo is a robust, plug and play system which can be installed quickly and securely.
The pure aluminium extrusion provides high thermal conductivity, increasing the lifetime of the LED's and the LED driver. Fitted with an opaque diffuser angled at 30° ensures optimum projection and uniformity.
Available in 4 lengths with an optional 170mm male to female coupler, the Abdo can be configured to provide continuous illumination up to 8m in length with great flexibility to suit application demands.
The fully contained structure can easily be cleaned and maintained with minimal effort or damage to the LED light source.
Abdo LED Cove Light provides a discreet, robust solution for commercial concealed illumination.
|
Product
Code |
Power |
Lumen
Output |
LED
Colours |
CRI |
Beam
Angle(s) |
LED
Quantity |
IP
Rating |
Input
Voltage |
Input
Current |
Dimensions |
Mounting
Type |
Weight | Warranty |
| ARC-WW-ABD030 | 3W | 180lm | 3000K | 4000K | 6000K | ≥90 | 120° | 6 | IP20 | 220 - 24VAC | - | 300mm | Surface | 135g | 3 years |
| ARC-WW-ABD060 | 6W | 360lm | 3000K | 4000K | 6000K | ≥90 | 120° | 12 | IP20 | 220 - 24VAC | - | 600mm | Surface | 185g | 3 years |
| ARC-WW-ABD090 | 10W | 600lm | 3000K | 4000K | 6000K | ≥90 | 120° | 20 | IP20 | 220 - 24VAC | - | 900mm | Surface | 250g | 3 years |
| ARC-WW-ABD120 | 12W | 720lm | 3000K | 4000K | 6000K | ≥90 | 120° | 24 | IP20 | 220 - 24VAC | - | 1,200mm | Surface | 310g | 3 years |
