Cracens LED wall washers sleek design allows for concealed illumination with maximum effect. The distinctive body is not only stylish element of the design but ensures high heat dissipation, keeping the lamp cool, prolonging its life.
The units are supplied with input & output, IP65, M12 Connectors allowing them to be daisy chained.
Operating at DC, the Cracens wall washer is compatible with a wide range of controls for dimming or colour changing. A variety of lengths, colours & beam angles give great flexibility for different applications.
Cracens LED wall washer delivers outstanding uniformity for facade illumination.
|
Product
Code |
Power |
Lumen
Output |
LED
Colours |
CRI |
Beam
Angle(s) |
LED
Quantity |
IP
Rating |
Input
Voltage |
Input
Current |
Dimensions |
Mounting
Type |
Weight | Warranty |
| ARC-WW-CRA030 | 7W | 630lm |
2700K | 4000K | 6000K
Red | Green | Blue | Amber |
≥80 |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
6 | IP65 | 24VDC | - | 300mm | Surface | 0.6kg | 3 years |
| ARC-WW-CRA060 | 14W | 1,260lm |
2700K | 4000K | 6000K
Red | Green | Blue | Amber |
≥80 |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
12 | IP65 | 24VDC | - | 600mm | Surface | 1.2kg | 3 years |
| ARC-WW-CRA090 | 21W | 1,890lm |
2700K | 4000K | 6000K
Red | Green | Blue | Amber |
≥80 |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
18 | IP65 | 24VDC | - | 900mm | Surface | 1.8kg | 3 years |
| ARC-WW-CRA120 | 28W | 2,520lm |
2700K | 4000K | 6000K
Red | Green | Blue | Amber |
≥80 |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
24 | IP65 | 24VDC | - | 1,200mm | Surface | 2.4kg | 3 years |
| ARC-WW-CRA030-RGB | 10W | - | RGB | - |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
9
(3R, 3G, 3B) |
IP65 | 12VDC | - | 300mm | Surface | 0.6kg | 3 years |
| ARC-WW-CRA060-RGB | 20W | - | RGB | - |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
18
(6R, 6G, 6B) |
IP65 | 24VDC | - | 600mm | Surface | 1.2kg | 3 years |
| ARC-WW-CRA090-RGB | 30W | - | RGB | - |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
27
(9R, 9G, 9B) |
IP65 | 12VDC | - | 900mm | Surface | 1.8kg | 3 years |
| ARC-WW-CRA120-RGB | 40W | - | RGB | - |
10° | 15° | 25°
45° | 60° | 120° 10x45° | 25x60° |
36
(12R, 12G, 12B) |
IP65 | 24VDC | - | 1,200mm | Surface | 2.4kg | 3 years |
