The Altum Downlight operates at 90lm/W, incorporating a pure aluminium heatsink which provides exceptional heat dissipation to prolong the life of the lamp.
Altum LED Downlights generate a natural distribution of illumination with high uniformity and a comfortable UGR of <19.
Cost-effective and versatile lighting, the Altum LED Downlight family is avaiailable in 3 sizes to accommodate various cut-outs and 3 beam angles.
TRIAC dimmable as standard with optional DALI or 1-10V dimming, it is easy to integrate the Altum LED Downlight into existing installations.
The Altum LED Downlights are most at home in Commercial Offices, Hotels, Restaurants & Retail Stores.
|
Product
Code |
Power |
Lumen
Output |
LED
Colours |
CRI |
Beam
Angle(s) |
IP
Rating |
Input
Voltage |
Input
Current |
Dimming |
Mounting
Type |
Dimensions | Cutout | Weight | Warranty |
| COM-DL-ALT13 | 13W | 1,000lm | 27000K | 4000K | 5000K | ≥80 | 45° | IP20 | 42VDC | 300mA | CC | Recessed | ∅110mm | ∅95mm | 380g | 3 years |
| COM-DL-ALT25 | 25W | 2,550lm | 27000K | 4000K | 5000K | ≥80 | 36° | IP20 | 40VDC | 600mA | CC | Recessed | ∅190mm | ∅165mm | 850g | 3 years |
| COM-DL-ALT35 | 35W | 3,550lm | 27000K | 4000K | 5000K | ≥80 | 45° | IP20 | 40VDC | 800mA | CC | Recessed | ∅230mm | ∅205mm | 1.2kg | 3 years |
| COM-DL-ALT13-TR | 13W | 1,000lm | 27000K | 4000K | 5000K | ≥80 | 45° | IP20 | 220-240VAC | - | TRIAC | Recessed | ∅110mm | ∅95mm | 380g | 3 years |
| COM-DL-ALT25-TR | 25W | 2,550lm | 27000K | 4000K | 5000K | ≥80 | 36° | IP20 | 220-240VAC | - | TRIAC | Recessed | ∅190mm | ∅165mm | 850g | 3 years |
| COM-DL-ALT35-TR | 35W | 3,550lm | 27000K | 4000K | 5000K | ≥80 | 45° | IP20 | 220-240VAC | - | TRIAC | Recessed | ∅230mm | ∅205mm | 1.2kg | 3 years |
