Minima LED Downlights

Product Overview
Features
- Bridgelux COB LED

- Deep cylinder design

- Frosted PMMA lens / RAL9016 bezels

- TRIAC, DALI & 1-10V Dimmable Options

- 3 Step macadam ellipse

- 3 year warranty
Description

Minima LED downlights are a compact, stylish LED downlight for residential & commercial applications.

Cut-out options ranging from ∅35mm to ∅55mm, Minima LED downlights are an ideal option for local lighting applications where a small form factor is required.

The minimal appearance allows discreet placement whilst the deep cylinder design with optional beam angles delivers low glare, controlled illumination for refined installations.

Remote LED driver and pure aluminium heatsink ensures excellent thermal management, prolonging the life of the lamp.

0/1-10V, TRIAC & DALI dimmable options allow multi-platform integration for new or existing lighting systems.

Options
Colours:

27000K

3000K

4000K
Beam Angles:
10° | 15° | 24° | 36°
Finish:
White (RAL9016)
Dimming:
TRIAC | DALI | 1-10V
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
IP
Rating
Input
Voltage
Input
Current
Dimming Mounting
Type
Dimensions Cutout Weight Warranty
COM-DL-MIN135X 1W 60lm 2700K | 3000K | 4000K ≥90 10° | 15° IP20 4VDC 250mA CC Recessed ∅45mm ∅35mm 80g 3 years
COM-DL-MIN135 1W 60lm 2700K | 3000K | 4000K ≥90 10° | 15° IP20 4VDC 250mA CC Recessed ∅45mm ∅35mm 120g 3 years
COM-DL-MIN345 3W 150lm 2700K | 3000K | 4000K ≥90 10° | 15° | 24° IP20 5VDC 700mA CC Recessed ∅55mm ∅45mm 150g 3 years
COM-DL-MIN755 7W 350lm 2700K | 3000K | 4000K ≥90 15° | 24° | 36° IP20 30VDC 250mA CC Recessed ∅65mm ∅55mm 240g 3 years
COM-DL-MIN135X-SW 1W 60lm 2700K | 3000K | 4000K ≥90 10° | 15° IP20 110-240VAC 0.004A @ 230VAC TRIAC Recessed ∅45mm ∅35mm 80g 3 years
COM-DL-MIN135-SW 1W 60lm 2700K | 3000K | 4000K ≥90 10° | 15° IP20 110-240VAC 0.004A @ 230VAC TRIAC Recessed ∅45mm ∅35mm 120g 3 years
COM-DL-MIN345-SW 3W 150lm 2700K | 3000K | 4000K ≥90 10° | 15° | 24° IP20 110-240VAC 0.013A @ 230VAC TRIAC Recessed ∅55mm ∅45mm 150g 3 years
COM-DL-MIN755-SW 7W 350lm 2700K | 3000K | 4000K ≥90 15° | 24° | 36° IP20 110-240VAC 0.03A @ 230VAC TRIAC Recessed ∅65mm ∅55mm 240g 3 years
Optical Performance
Mini Recessed LED Ceiling Light
Dimensions
Minima LED Downlights
Control Options
0/1 - 10V
2.4GH
z
RF
DALI
DMX
TRIAC
