Muto V3 Twin Spots

Product Overview
Features
- Bridgelux COB LED

- Deep cylinder modular design

- Frosted PMMA lens / RAL9016 bezels

- TRIAC, DALI & 1-10V Dimmable Options

- IP20

- 3 Step macadam ellipse

- 3 year warranty
Description

Muto LED Downlight is a stylish, versatile LED downlight for residential & commercial applications.

The modular die cast aluminium engine is fitted with interchangeable baffles to suit various applications. The pure aluminium heatsink provides excellent thermal conductivity to prolong the life of the lamp.

Deep cylinder design delivers low glare illumination for refined installations.

TRIAC dimmable as standard with optional DALI & 1-10V dimming, it is easy to integrate the Muto V3 LED Downlight into existing installations.

The Muto V3 LED Downlight is most at home in Commercial Offices, Hotels, Restaurants & Retail Stores.

Options
Colours:

27000K

3000K

4000K
Beam Angles:
15° | 24° | 40°
Finishes:
Black (RAL9005) | White (RAL9016)
Dimming:
TRIAC | DALI | 1-10V
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
IP
Rating
Input
Voltage
Input
Current
Dimming Mounting
Type
Dimensions Cutout Weight Warranty
COM-DL-MUV312-B 24W 1,600lm 2700K | 3000K | 4000K ≥90 15° | 24° | 40° IP20 220-240VAC - TRIAC Recessed - 200x100mm 1.7kg 3 years
COM-DL-MUV318-B 36W 2,400lm 2700K | 3000K | 4000K ≥90 15° | 24° | 40° IP20 220-240VAC - TRIAC Recessed - 260x125mm 2.55kg 3 years
COM-DL-MUV330-B 60W 4,000lm 2700K | 3000K | 4000K ≥90 15° | 24° | 40° IP20 220-240VAC - TRIAC Recessed - 310x160mm 3.4kg 3 years
Dimensions
Control Options
0/1 - 10V
2.4GH
z
RF
DALI
DMX
TRIAC
