Gyrus is a modern, LED alternative to a traditional 2D CFL bulkhead.
Ceiling or wall mounted, the Gyrus 2D LED bulkhead is manufactured from V0 fire rated polycarbonate finished in either black or white, allowing an additional level of creative personality for charismatic installations.
IP54 as standard, Gyrus 2D LED bulkheads are comfortable in damp or wet locations, and are available with dimming, CCT adjust, motion detection, daylight detection and emergency options to meet the requirements of commercial integration.
Gyrus 2D LED bulkheads provide up to 70% energy savings when compared to traditional CFL 2D bulkheads offering significant energy reduction in commercial corridors, hallways or stairways.
|
Product
Code |
Power |
Lumen
Output |
LED
Colours |
CRI |
Beam
Angle(s) |
#
LED's |
IP
Rating |
Input
Voltage |
Input
Current |
Control | Dimensions |
Mounting
Type |
Weight | Warranty |
| COM-SU-GYR2012A | 12W | 1,265lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC | - | ∅200mm | Surface | 420g | 3 years |
| COM-SU-GYR2012B | 12W | 1,265lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC |
TRIAC
CCT Switch |
∅200mm | Surface | 420g | 3 years |
| COM-SU-GYR2012C | 12W | 1,265lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC | Motion | ∅200mm | Surface | 420g | 3 years |
| COM-SU-GYR2512A | 12W | 1,265lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC | - | ∅250mm | Surface | 700g | 3 years |
| COM-SU-GYR2512B | 12W | 1,265lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC |
TRIAC
CCT Switch |
∅250mm | Surface | 700g | 3 years |
| COM-SU-GYR2512C | 12W | 1,265lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC |
Daylight
Motion |
∅250mm | Surface | 700g | 3 years |
| COM-SU-GYR2512D | 12W | 1,265lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.07A @ 230VAC |
Emergency
Daylight Motion |
∅250mm | Surface | 700g | 3 years |
| COM-SU-GYR3018A | 18W | 1,905lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.09A @ 230VAC | - | ∅300mm | Surface | 880g | 3 years |
| COM-SU-GYR3018B | 18W | 1,905lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.09A @ 230VAC |
TRIAC
CCT Switch |
∅300mm | Surface | 880g | 3 years |
| COM-SU-GYR3018C | 18W | 1,905lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.09A @ 230VAC |
Daylight
Motion |
∅300mm | Surface | 880g | 3 years |
| COM-SU-GYR3018D | 18W | 1,905lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.09A @ 230VAC |
Emergency
Daylight Motion |
∅300mm | Surface | 880g | 3 years |
| COM-SU-GYR3025A | 25W | 2,570lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC | - | ∅300mm | Surface | 1.03kg | 3 years |
| COM-SU-GYR3025B | 25W | 2,570lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC |
TRIAC
CCT Switch |
∅300mm | Surface | 1.03kg | 3 years |
| COM-SU-GYR3025C | 25W | 2,570lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC |
Daylight
Motion |
∅300mm | Surface | 1.03kg | 3 years |
| COM-SU-GYR3025D | 25W | 2,570lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC | Emergency | ∅300mm | Surface | 1.03kg | 3 years |
| COM-SU-GYR3025E | 25W | 2,570lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC |
Emergency
Daylight Motion |
∅300mm | Surface | 1.03kg | 3 years |
| COM-SU-GYR3525A | 25W | 2,570lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC | - | ∅350mm | Surface | 1.3kg | 3 years |
| COM-SU-GYR3525B | 25W | 2,570lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.28A @ 230VAC |
TRIAC
CCT Switch |
∅350mm | Surface | 1.3kg | 3 years |
| COM-SU-GYR4030A | 30W | 3,085lm | 3000K | 4000K | 5000K | 5700K | ≥80 | 120° | - | IP54 | 220-240VAC | 0.46A @ 230VAC | - | ∅400mm | Surface | 1.4kg | 3 years |
| COM-SU-GYR4030B | 30W | 3,085lm |
3000K / 4000K / 5700K
(Switchable) |
≥80 | 120° | - | IP54 | 220-240VAC | 0.46A @ 230VAC |
TRIAC
CCT Switch |
∅400mm | Surface | 1.4kg | 3 years |
