Octo LED Surface Fixtures

Product Overview
Features
- Modern geometric design

- Diffused acrylic cover

- Soft, uniform illumination

- 4 size variants

- 6 colour optoins

- IP20

- 2 year warranty
Description

Octo is a diffused, surface mounted geometric LED light fixture incorporating an octagonal body with faceted sides for a contemporary look.

Ceiling or wall mounted, Octo LED surface fixtures are manufactured from aluminium in 4 sizes, finished with a choice of six colour options, ensuring a greater level of individuality for creative installations.

The Octagonal PMMA diffuser ensures a natural, comfortable light output with soft shadows and remote driver options allow dimming operation via DALI, DMX, TRIAC or 0/1-10V.

Octo LED surface fixtures wide array of configurations combine function with form, stylized for contemporary commercial offices, restaurants & hotels.

Options
Colours:

3000K

4000K

6000K
Beam Angle:
120°
Finishes:
Black | White
Blue | Green | Pink | Yellow
Technical Specifications
Product
Code
Power Lumen
Output
LED
Colours
CRI Beam
Angle(s)
#
LED's
IP
Rating
Input
Voltage
Input
Current
Control Dimensions Mounting
Type
Weight Warranty
COM-SU-OCT30 18W 1,350lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 32VDC 550mA CC 300mm Surface 3.25kg 2 years
COM-SU-OCT40 24W 1,800lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 42VDC 550mA CC 400mm Surface 3.5kg 2 years
COM-SU-OCT50 36W 2,700lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 48VDC 750mA CC 500mm Surface 3.75kg 2 years
COM-SU-OCT60 42W 3,150lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 36VDC 1200mA CC 600mm Surface 4kg 2 years
COM-SU-OCT30-TR 18W 1,350lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 220-240VAC - TRIAC 300mm Surface 3.25kg 2 years
COM-SU-OCT40-TR 24W 1,800lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 220-240VAC - TRIAC 400mm Surface 3.5kg 2 years
COM-SU-OCT50-TR 36W 2,700lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 220-240VAC - TRIAC 500mm Surface 3.75kg 2 years
COM-SU-OCT60-TR 42W 3,150lm 3000K | 4000K | 6000K ≥80 120° 1 IP20 220-240VAC - TRIAC 600mm Surface 4kg 2 years
Dimensions
Control Options
0/1 - 10V
2.4GH
z
RF
DALI
DMX
TRIAC
